Turn an engineering drawing into a STEP model, or describe a part in plain English.
Watch a scanned print become a checked STEP file. Upload, AI reads every dimension, builds the model, checks every feature, you download the part and the quality report.
Upload a PDF or image of a 2D print. AI reads every view and dimension, builds the solid, and checks it back against your drawing. STEP + STL + quality report, in minutes.
Say what you need in plain English. The Studio turns it into real parametric geometry you can keep refining by chat, then exports STEP, STL, 3MF or GLB.
Just need to open or convert a file? Free 3D viewer & converter → STEP, STL, OBJ, IGES, DXF, GLB. Sign up (free) to download.
Upload a PDF or image of an engineering drawing. AI reads every view and dimension, builds a solid 3D model, and checks it back against your drawing. You get STEP and STL files, plus a quality report.
Free check first. Nothing charged until you say go.
A whole drawer of prints? Volume pricing for shops and teams →
No drawing? Stop wrestling with CAD menus and just say what you need. PartWork's AI understands dimensions, standard hardware and manufacturing constraints, and keeps refining the part as you talk.
"Create a 4x3x1 inch mounting bracket with four M4 countersunk holes in the corners"Whether it came from a drawing or a sentence, you get real B-rep solid geometry with precise dimensions, ready for CNC machining and 3D printing.
"50.5mm" means exactly 50.5mm, not an approximation. Tolerances you can trust for real manufacturing.
Industry-standard B-rep geometry, not polygonal meshes. Export STEP and open it in any CAD package with full editability.
Fusion 360, SolidWorks, Onshape, FreeCAD, or any instant-quote service. STEP in, STL and 3MF for your slicer.
All in your browser, on any device.
PDF or image of a 2D print → STEP + STL, checked against the drawing.
Free check firstPlain-English prompt → manufacturable solid geometry in the Studio.
Free trial creditsSTEP, STL, OBJ, IGES, BREP, DXF or GLB. Orbit, zoom, inspect on phone or desktop.
FreeSTEP ⇄ STL, 3MF, GLB. View free; sign up (free) to download.
Free to viewOpen a CAD file right in your browser. Free, nothing to install.
STEP, STL, OBJ, IGES, BREP, DXF or GLB. One place to open any of them.
Exact CAD geometry, with no triangle limit.
The 3D printing standard, rendered in your browser.
Meshes from scanning, sculpting and AI generators.
Web and AR models, plus the code to embed them.
Legacy CAD surfaces, from .iges and .igs files.
Turn an exact solid into a printable mesh.
Turn a print mesh into a STEP solid for CAD or a machine shop.
Generate a printable spur gear to spec.
Running your own site? Embed the viewer on any page with one line.
See how we compare to traditional CAD.
Generate STEP and mesh files from text prompts, or submit drawings for conversion, from your own application via a simple REST API.
View Developer DocsFour steps, all by email and in your browser:
Yes. The preview page shows the 3D model and the quality report first. Nothing is charged until you choose to buy.
Every view on your drawing is compared with the same view of the model, and every dimension is checked. The quality report shows the result on your preview page. If the drawing leaves something out, our AI will reach out and ask you.
Any drawing of a single part, as a PDF (2 pages max), JPG or PNG up to 10 MB. Old prints, scans and photos work if the views and dimensions are legible. Assemblies, freeform surfaces and drawings with missing views are not supported yet; the free check tells you before you pay.
Yes. Your drawing is never used to train AI and never sold, and it is deleted after 90 days, or sooner if you ask.
Bring a drawing, or bring an idea. Either way you leave with a real STEP file.
Drawings: free check first, pay per part. Studio: free to upload & view, sign up (free) to download, free trial credits to generate.
